PNJ_PNS-BA-e-1612 73
11.4 Remote control instructions
General order format:
Consisting of 4 characters including the terminators (CR, LF).
C1 C2 CR LF
Subsequent commands will be detected by the weighing scale.
1. Data output
C1 C2 Code (C1) Code (C2) Function Response
O 0 4FH 30H No data output
A00: Free from error
E01: Error message
O 1 4FH 31H Continuous data output
O 2 4FH 32H
Continuous data output stable
weighing values
O 3 4FH 33H
Output for stable and instable
weighing values after pressing
PRINT key
O 4 4FH 34H
Output for stable weighing value
after previous relief of balance
O 5 4FH 35H
One output for stable weighing
value. No output for stable
weighing values. Renewed
output after stabilization
O 6 4FH 36H
One output for stable weighing
value. Continuous output for
instable weighing values.
O 7 4FH 37H
Output of stable weighing values
after pressing PRINT key
O 8 4FH 38H Single immediate output
O 9 4FH 39H Single output after stabilization
