User Manual
SUPM1
page 11 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
94
Functions and Specifications
Table 3: Main functions and specifications
Feature Rating or standard Release
16 PSTN user ports according to ITU-T Q.552 ITU-T Q.552 (11/2001)
Transmission characteristics at 2-wire analogue
interfaces of digital exchanges
ITU-T G.711 (1988)
r1a
Pulse Code Modulation (PCM) of voice frequencies r1a
BORSCHT functionality: Battery feed
Overvoltage protection
Ringing injection
Supervision
Codec
Hybrid
Testing
r1a
Voice impedances configurable for different countries
and applications
ITU-T Q.552 (11/2001)
Transmission characteristics at 2-wire analogue
interfaces of digital exchanges
r1a
Input and output level configuration ITU-T G.712 (11/2001)
Transmission performance characteristics of pulse
code modulation channels
r1a
Input and output overvoltage protection
According to ITU-T K.20, enhanced test level with
acceptance criteria A.
Note:
External primary protection (230V Gas Discharge
Tubes) is mandatory
ITU-T K.20 (07/2003)
Resistibility of telecommunication equipment
installed in a telecommunications centre to overvolt-
ages and overcurrents
r1a
Connector DIN 41612 r1a
V5CAS mode of operation (internal communication) r1a
MCAS modes of operation Technical specification for customer signalling in
public networks:
T 0197, Mercury Communications Ltd., 1990
Analogue 2-wire signalling state diagrams:
C6 0193 Issue 2, Mercury Communications Ltd,
1996
r1a
Phone-Exchange mode of operation r1a
Phone-Phone mode of operation r1a
Pulsed no battery type “a-wire disconnected”
Pulsed no battery type “a-b-wire disconnected”
NZ PTC 107, 6.5 r1a
Wetting current BT, SIN 242 Issue 2.2, November 2002
“Calling Line Identification Service”
r1a
Onboard ringing generator r1a
Onboard line-test function r1a
Thermal management r1a
Protection against equipment damage caused by faulty
installation of cables
r1a
Front panel access. One shielded cable is connected to
the front panel. It carries all 16 subscriber lines
r1a
No hardware settable options on the unit. All unit
parameters are software settable with the Element Man-
ager
r1a
