User Manual
SUPM1
page 28 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
94
Installation
4.2 Slots and Deployment Scenarios for the SUPM1 Unit
The SUPM1 unit uses one slot in the XMC20 subrack.
In a XMC20, the SUPM1 unit can be operated in any of the following slots:
• XMC25: 1 … 10, 12 … 21.
• XMC23: 7 … 10, 12 … 14.
• XMC22: 9 … 10, 12.
Slot 11 is reserved for the working COGE5 unit.
In maximum 20 SUPM1 units (without network connection) can be operated
in a XMC25. The number of SUPM1 units is reduced when using TDM trans-
port units as connection to the TDM network.
Figure 3: XMC25subrack with 19 SUPM1 units and 1 STM14 unit
The example above shows a XMC25 subrack equipped with 19 SUPM1
units, i.e. 304 user ports, which can be transported over a number of 2 Mbit/s
links over the TDM network.
Figure 4: XMC23 subrack with 6 SUPM1 units and 1 SELI8 unit
The example above shows a XMC23 subrack equipped with 6 SUPM1 units,
i.e. 96 user ports, which can be transported over a number of 2 Mbit/s links
over the TDM network.
In maximum 19 SUPM1 units (304 subscribers) can be operated in a XMC25
when using a high capacity VOIP1 media gateway unit.
n x 2 Mbit /s
Slot
1
Slot
11
Slot
21
TDM
Network
XMC25
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
C
O
G
E
5
S
T
M
1
4
n x 2 Mbit/s
Slot
7
Slot
11
Slot
14
TDM
Network
XMC23
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
S
U
P
M
1
C
O
G
E
5
S
E
L
I
8
