User Interface Reference
8 User Interface Reference
This section gives a complete reference of the managed objects, properties,
and commands of the SUPM1 service unit as far as these are not covered in
the generic descriptions in [302] User Guide “XMC25/XMC23/XMC22”.
For a description on how to configure and bring into operation the SUPM1
unit and its main functions, please refer to section 6 Commissioning (on
page 61).
8.1 Introduction
Below, you will find a detailed description of all the configuration parameters
and operations belonging to the managed objects model (MOM) for the
SUPM1 service unit.
The Figure 20 "MOM (managed object model) of the SUPM1 unit" shows the
access point (AP) tree for the SUPM1 unit with its managed objects:
Figure 20: MOM (managed object model) of the SUPM1 unit
With these managed objects (MOs) the following functions are covered:
For each of the managed objects, properties and commands, the GUI “Tree
Views” are given.
This reference section comprises the management functions:
Table 36: Managed objects (MOs) for SUPM1
MO Description of the management functions
unit-x: SUPM1 Rxx
(supm1_r2b)
Restart of the unit, management of the unit ESW, labelling,
indication of equipment status, read of inventory data, access
to logbooks, indication of temperature problems. Configuration
of unit parameters and line-test parameters.
The detailed properties are described in section 8.2 AP: / unit-
x: SUPM1 (on page 70).
port-y Management of PSTN port related functions, like the level con-
figuration and line-test status.
The detailed properties are described in section 8.3 AP: / unit-x
/ port-y (on page 82).
<ap >
<ap>
port-y
<ap >
0...20
16
