8.3 AP: / unit-x / port-y
8.3.1 AP: / unit-x, Overview
For a description of the
− “Overview - Alarms”,
− “Overview - Cross Connections”, and
− “Overview - CTP”
management functions, please refer to [302] User Guide “XMC25/XMC23/
XMC22”.
8.3.2 AP: / unit-x / port-y, Main
8.3.2.1 AP: / unit-x / port-y, Main - General
For a description of the
− “Main - General”
management function, please refer to [302] User Guide “XMC25/XMC23/
XMC22”.
8.3.2.2 AP: / unit-x / port-y, Main - Admin And Oper Status
Table 46: AP: / unit-x / port-y, Main - Admin And Oper Status
Operation Name Parameter Name Range Description / Details
Administrative Sta-
tus
State Up
Set the IETF administrative status of the port.
Down
Operational Status State Up
Display of the IETF operational status of the port.
Down
Testing
Unknown
Dormant
Not Present
Lower Layer Down
