Keymile SUPM1 - Page 83

User Manual
SUPM1
page 83 of 94© KEYMILE December 2015 EN/LZTBU 372 129/1 RC
94
User Interface Reference
8.3.3 AP: / unit-x / port-y, Configuration
8.3.3.1 AP: / unit-x / port-y, Configuration - General
Table 47: AP: / unit-x / port-y, Configuration - General
Operation Name Parameter Name Range Description / Details
Provisioning Set Provisioning Set Set 1
Port assignment to one of the predefined pro-
visioning sets. Provisioning sets are defined
on the unit configuration AP.
Set 2
Port Configuration Loop Current 15 mA
Select the appropriate loop current.
19.5 mA
23.5 mA
30 mA
39 mA
45 mA
Input Level -4.0 … 0.0 … 4.0 dBr,
step 0.5
Analogue input level referred to 0 dBr in the
digital domain.
Output Level -10.0 … -7.0 … 0.0 dBr,
step 0.5
Analogue output level referred to 0 dBr in the
digital domain.
Priority Normal
High priority subscribers are able to do new
calls also when the SUPM1 unit is in over-
heat state 1 or in power state 2.
Refer to section 5.12 Thermal Management
(on page 58) and to section 5.13 Power Man-
agement (on page 59).
In the V5CAS and MCAS direct line opera-
tion modes, maximum 3 high priority sub-
scribers can be configured per unit.
In all other operation modes the priority con-
figuration has no effect.
High
Enable Cyclic Test
Cyclic line-tests are only performed if this
parameter is set to true.
Enable DSL Adap-
tation (Combo only)
This property is ignored by the SUPM1 unit.
