The cable route on the cable tray should follow approximately the projection
of the unit slot on the cable tray.
In the XMC23 and XMC22, cables connecting to the SUPM1 unit or other
units should be guided and attached similarly to the way shown in Figure 7
"Side view of the cable tray and the cable in XMC25" above. For more
detailed information, please refer to [310] User Guide “XMC23 Installation” or
refer to [322] User Guide “XMC22 Installation”.
