Keyscan CA8500B - Figure 5 - Plastic Stand off; Figure 6

To Next Page

To Previous Page

Keyscan Inc. – Technical Guide (PC109x - 07.15)

Figure 5 – Plastic Stand Off

Figure 6 – Mounting Power Supplies

STAND OFF

into enclosure hole

into circuit board

KI-00106E-07-11

Hex Nuts x 2

Bolts x 2

Top of ACU

Enclosure

x 2

Control

Board

Top mount location for

DPS-15 power supply

with CAS6105 plug-in

cable to PSC1 terminal.

KI-00107E-06-12
