Keysight 16452A Liquid Test Fixture 15
Initial Inspection
Product Overview
Table 2-1 Contents
Reference
Designator
Description Part Number Quantity
1 Liquid test fixture 16452A 1
O-ring for electrodes
1
0905-1275 2
2 Shorting plate 16092-08010 1
3 O-ring for liquid outlet 0905-1277 1
4Spacer
1.3mm (thickness)/
0.3 mm (gap)
2
16452-00601 1
1.5mm (thickness)/
0.5 mm (gap)
16452-00602 1
2.0mm (thickness)/
1.0 mm (gap)
16452-00603 1
3. 0m m (thickness)/
2.0 mm (gap)
16452-00604 1
5 lid of liquid outlet 16452-24002 1
6 SMA-BNC adapter 1250-1200 4
- Waterproof cap for BNC
connector
3
1252-5831 4
-
Carrying Case
4
16452-60111 1
-
Operation and Service Manual
4
16452-90000 1
-
Fixture stand
5
Stand body
-
6
1
Screw for stand 0515-0914 4
Stand foot 16452-00611 1
1.
The O-rings are assembled in the 16452A.
2. The 1.3mm spacer is assembled in the 16452A.
3. The cap is on the SMA-BNC adapter.
4. The carrying case and the Operation and Service Manual are not shown in the
Figure 2-1.
5. The fixture stand is shown in Figure 2-2. Assemble it as shown in the figure.
