Keysight 16452A Liquid Test Fixture 39
Service
Assembly Replacement
4 16092-08010 Shorting Plate 1 16092-08010 Shorting Plate 1
5 0905-1275 O Ring 2 0905-1275 O Ring 2
6 16452-24002 Lid of Liquid
Outlet
1 16452-24002 Lid of Liquid
Outlet
1
0905-1277 O Ring for Lid 1 0905-1277 O Ring for Lid 1
7 16452-60001 High Electrode
Assembly
1 16452-60001 High Electrode
Assembly
1
8 1250-1200 SMA(m)-BNC(f)
Adapter
4 1250-1200 SMA(m)-BNC(f)
Adapter
4
Table 4-2 Replaceable Parts (Other Parts)
Part Number Description Qty RoHS
Compliant
Replacement
Part
Description Qty
16452-04001 Round Cover for
Back of the
Electrode
2 16452-60001/
16452-60002
High Electrode
Assembly/
Low Electrode
Assembly
1
0905-1276 Washer, Teflon 2 16452-60001/
16452-60002
High Electrode
Assembly/
Low Electrode
Assembly
1
0515-0994 Spacer 8 16452-60001/
16452-60002
High Electrode
Assembly/
Low Electrode
Assembly
1
1252-5831 Waterproof Cap
for BNC
Connector
4 1252-5831 Waterproof Cap
for BNC
Connector
4
16452-01201 Angle Iron for the
Stand
2 16452-01201 Angle Iron for the
Stand
2
Table 4-1 Replaceable Parts (Major Parts)
Ref
/D
Part Number Description Qty RoHS
Compliant
Replacement
Part
Description Qty
