Keysight Models 6811C, 6812C, and 6813C Quick Start Guide 15
Synchronize transient
events or
measurements with
external signals
Operate in four
transient modes
Operate under local
or remote control
– From the front panel keys
– Through the built-in GPIB, RS-232, LAN, and USB interfaces
Implement protection
features
–Overvoltage
– Overcurrent
–Overpower
– Overtemperature
– User-defined external events (via a fault (FLT) shutdown signal)
Feature Description
Triggers applied
to the ac source
Triggers generated
by the ac source
External TTL
signal
Bus supplied trigger
(RS-232, GPIB, USB
or LAN
+
Trigger
Trigger
IN
OUT
IN
OUT
TTL
trigger
Fixed Step Pulse List
