50 Keysight Models 6811C, 6812C, and 6813C Quick Start Guide
Programming Trigger Synchronization and Delays
The previous transient examples were programmed to respond to immediate
triggers. However, delayed and phase synchronized triggers can also be
programmed as shown in the following examples.
No delay; no phase synchronization
Key press and display Result
VOLT:M STEP
VOLT 120
VOLT:T 150
DELAY 0
SYNC:SOUR IMM
INIT:IMMED
When these commands are sent, the voltage amplitude changes
immediately upon the receipt of a trigger.
VOLT level
TRIG level
Trigger
