20 Keysight Models 6811C, 6812C, and 6813C Quick Start Guide
Function keys
– If is displayed, press [Enter] to display the information for the command
or save the command settings.
– If and are displayed, use ▲ or ▼ of the function keys or entry keys to
scroll up or down to display the information.
Function
key press
Function command on
the front panel display
Entry key press Description
Use ▲ or ▼ to
navigate between
the Meter function
commands.
<reading> V <reading> Hz -
Display rms voltage and
frequency.
<reading> V <reading> A -
Display rms voltage and rms
current.
<reading> A <reading> Hz -
Display rms current and
frequency.
<reading> V <reading> W - Display rms voltage and power.
<reading> CREST F - Display current crest factor.
<reading> A PK REP - Display peak current, repetitive.
<reading> A PK NR -
Display peak current,
non-repetitive.
<reading> VA - Display apparent power.
<reading> VAR - Display reactive power.
<reading> PFACTOR - Display power factor.
