Keysight Models 6811C, 6812C, and 6813C Quick Start Guide 43
Key press Display (voltage function command parameters)
1 Press .
2 Press ▲ or ▼ of the Function
key group to access the ac
source measurement features.
120 V 60 HZ rms voltage and frequency
120 V 1.925 A rms voltage and current
1.93 A 60 HZ rms current and frequency
120 V 150.5 W rms voltage and power
2.82 CREST F current crest factor
5.379 A PK REP peak current, repetitive
36.83 A PK NR peak current, non repetitive
230.6 VA apparent power
175.2 VAR reactive power
0.65 PFACTOR power factor
