Installing Front Handles/Rack Mounting Flanges
The E4982A can be installed on a workbench or in a rack.
This section describes how to install the front handles
(Option 1CN) used for moving or transporting the
instrument, and how to install the meter in an equipment
rack as part of a measurement system (Option 1CM: without
the handles, Option 1CP: with the handles).
Table 1 Keysight E4982A handles/rack mounting options
Option Name Keysight Part Number
1CN Handle Kit 5063-9229
1CM Rack-mount Kit 5063-9216
1CP Rack-mount and Handle Kit 5188-4430
Table 2 Contents of each option
Option Contents Quantity
1CN Front Handles 2
Screws 6
Trim Strips 2
1CM Rack-mounting flanges (locking side plate) 2
Screws 6
1CP Rack-mounting flanges (locking side plate) 2
Front Handles 2
Screws 8
To Next Page
