Installation 1
LCR Meter 33
Power Supply
Before turning on the E4982A power, check the following.
Verification of the Power Supply
Confirm that the power supplied to the E4982A meets the
following requirements:
Verification and Connection of Power Cable
The three- wire power cable attached to the E4982A has one
wire serving as a ground. Using this power cable allows the
E4982A to be grounded, thereby protecting you against
electrical shock from the power outlet.
Step 1. Confirm that the power cable is not damaged.
Step 2. Use the supplied cable to connect between the
power cable receptacle (Figure 8 on page 36) on the rear
panel of the E4982A and a three- wire power outlet with the
grounding prong firmly connected in the ground slot.
Power cord list, 16000- 99101 shows the power cable options.
Requirements
Voltage 90 to 264 VAC (Vpeak > 120 V)
Frequency 47 to 63 Hz
Maximum power
consumption
300 VA
NEVER use a power cable showing any sign of damage. Faulty
cables can cause electrical shock.
Use the supplied power cable with grounding wire to securely
ground the E4982A.
