298 Keysight InfiniiVision 3000 X-Series Oscilloscopes User's Guide
20 Utility Settings
If the ground level is off screen, the waveform will expand about the top or
bottom edge of the screen based on where the ground is off screen.
• Center— The displayed waveform will expand about the center of the display.
To disable/enable transparent backgrounds
There is a preference setting for whether measurements, statistics, reference
waveform information, and other text displays have transparent or solid
backgrounds.
1 Press [Utility] > Options > Preferences.
2 Press Transparent to toggle between transparent and solid text display
backgrounds.
To load the default label library
See "To reset the label library to the factory default" on page 139.
To set up the screen saver
The oscilloscope can be configured to turn on a display screen saver when the
oscilloscope has been idle for a specified length of time.
1 Press [Utility] > Options > Preferences > Screen Saver to display the Screen Saver
Menu.
2 Press the Saver softkey to select the screen saver type.
The screen saver can be set to Off, to display any of the images shown in the
list, or can display a user-defined text string.
If User is selected, press the Spell softkey to select the first character of the text
string. Use the Entry knob to choose a character. Then press the Enter softkey
to advance to the next character and repeat the process.
You can use a connected USB keyboard instead of using the Spell (and other) character
editing softkeys.
