Keysight InfiniiVision 3000 X-Series Oscilloscopes User's Guide 9
Contents
InfiniiVision 3000 X-Series Oscilloscopes—At a Glance / 4
In This Guide / 6
1 Getting Started
Inspect the Package Contents / 25
Install the Optional LAN/VGA or GPIB Module / 28
Tilt the Oscilloscope for Easy Viewing / 28
Power-On the Oscilloscope / 29
Connect Probes to the Oscilloscope / 30
Maximum input voltage at analog inputs / 31
Do not float the oscilloscope chassis / 31
Input a Waveform / 31
Recall the Default Oscilloscope Setup / 32
Use Auto Scale / 32
Compensate Passive Probes / 34
Learn the Front Panel Controls and Connectors / 35
Front Panel Overlays for Different Languages / 41
Learn the Rear Panel Connectors / 43
Learn the Oscilloscope Display / 45
Access the Built-In Quick Help / 46
