Front Panel Overlays for Different Languages
Front panel overlays, which have translations for the English front panel keys and
label text, are available in 10 languages. The appropriate overlay is included when
the localization option is chosen at time of purchase.
To install a front panel overlay:
18. Demo 2, Ground, and
Demo 1 terminals
• Demo 2 terminal — This terminal outputs the Probe Comp signal which helps you match a
probe's input capacitance to the oscilloscope channel to which it is connected. See
"Compensate Passive Probes" on page 34. With certain licensed features, the
oscilloscope can also output demo or training signals on this terminal.
• Ground terminal — Use the ground terminal for oscilloscope probes connected to the Demo
1 or Demo 2 terminals.
• Demo 1 terminal — With certain licensed features, the oscilloscope can output demo or
training signals on this terminal.
19. USB Host port This port is for connecting USB mass storage devices or printers to the oscilloscope.
Connect a USB compliant mass storage device (flash drive, disk drive, etc.) to save or recall
oscilloscope setup files and reference waveforms or to save data and screen images. See
Chapter 18, “Save/Recall (Setups, Screens, Data),” starting on page 273.
To print, connect a USB compliant printer. For more information about printing see
Chapter 19, “Print (Screens),” starting on page 285.
You can also use the USB port to update the oscilloscope's system software when updates are
available.
You do not need to take special precautions before removing the USB mass storage device
from the oscilloscope (you do not need to "eject" it). Simply unplug the USB mass storage
device from the oscilloscope when the file operation is complete.
CAUTION: Do not connect a host computer to the oscilloscope's USB host port. Use the
device port. A host computer sees the oscilloscope as a device, so connect the host computer
to the oscilloscope's device port (on the rear panel). See "I/O Interface Settings" on
page 291.
There is a second USB host port on the back panel.
20. Digital channel
inputs
Connect the digital probe cable to this connector (MSO models only). See Chapter 6, “Digital
Channels,” starting on page 105.
21. Waveform generator
output
Outputs sine, square, ramp, pulse, DC, or noise on the Gen Out BNC. Press the [Wave Gen] key
to set up the waveform generator. See Chapter 17, “Waveform Generator,” starting on page
257.
