144 Keysight Agile Signal Generator Service Guide
Assembly Replacement
DAC/Reference/LB Switch Assembly
Tools Required
— T-10 driver
—Flat blade screwdriver
Removal Procedure
1. Disconnect the power cord.
2. Remove the outer-cover from the signal generator. Refer to “Outer Cover”
on page 99.
3. Place the signal generator flat with the front-panel facing you.
4. Remove the rear bottom cover from the signal generator. Refer to “Inner
Bottom Covers” on page 101.
5. Remove the rear panel. Refer to “Rear Panel” on page 151.
6. Refer to Figure 3-40. Remove semi-rigid cables W10 and W11 on the
Microdeck assembly.
It is extremely important to remove the two rigid cables W10 and W11 before proceeding with
this removal process. Failure to do so will damage the cables and boards.
