66 Keysight Agile Signal Generator Service Guide
Replaceable Parts
W31 Cable Assembly, Ribbon, Transfer Switch N5191-60113 2-20
W32 Cable Assembly, Ribbon, Mechanical Attenuator, UNM N5191-60114 2-20
W33 Cable Assembly, Ribbon, Front Panel N5191-60107 2-22
W34 Cable Assembly-Coaxial A31/A40 50-Ohm MCX-Male BNC-Female
750mm-LG, Color clip "Brown/Red" to "LF OUT", Option 1EM
8121-2580
W35 Cable Assembly-Coaxial A31/A40 50-Ohm MCX-Male BNC-Female
750mm-LG, Color clip "Brown/Orange" to "EXT 2", Option 1EM
8121-2580
W36 Cable Assembly-Coaxial A31/A40 50-Ohm MCX-Male BNC-Female
750mm-LG, Color clip "Brown/Yellow" to "EXT 1", Option 1EM
8121-2580
W37 Cable Assembly-Coaxial A31/A40 50-Ohm MCX-Male BNC-Female
600mm-LG, Color clip "Brown/Green" to "Gate Pulse Trigger", Option 1EM
8121-2582
W38 Cable Assembly-Coaxial A31/A40 50-Ohm MCX-Male BNC-Female
600mm-LG, Color clip "Brown/Blue" to "Sync Output", Option 1EM
8121-2582
W39 Cable Assembly-Coaxial A31/A40 50-Ohm MCX-Male BNC-Female
600mm-LG, Color clip "Brown/White" to "Video Output", Option 1EM
8121-2582
Table 2-2 Cables
Reference
Designator
Description Part Number Figure
Number
