Keysight Agile Signa
l Generator Service G
uid
e
Replaceab
le Parts
Figure 2-8
Rear Panel Assembl
ies
Item
Descr
iption
Part Number
1
A8 Solid State Drive
N5191-60139
2
A13 Module, L
VDS I/O Interfac
e (Rear Panel I/O Port)
N5191-60137
A13 Module, BCD I/O Interfa
ce (Rear Panel I/O Port)
N5191-60138
83
85
