Installation Note N5222-90131 11
Description of the Upgrade
Items Included in the Upgrade Kit
Items Included in the Upgrade Kit
Check the contents of your kit against the following list. If any part is missing or
damaged, contact Keysight Technologies. Refer to “Getting Assistance from
Keysight” on page 4.
Table 2 Contents of Upgrade Kit N5222-60131
Ref
Desig.
Description Qty Part Number
-- Installation note (this document) 1 N5222-90131
-- Software Entitlement Certificate (provided separately) 1 5964-5145
-- China RoHS Addendum 1 9320-6722
A8 26.5 GHz source (2) board 1 5087-7342
A11 Direct digital synthesizer (DDS) assembly, (x4) – (Replaces A11 x2 DDS assembly.) 1 N5240-60102
A22
a
Splitter 1 5087-7139
A24 Mixer brick (2) 1 5087-7829
A26 Test port 3 receiver bridge 2 5087-7757
A27 Test port 4 receiver bridge
A30 Test port 3 coupler 2 5087-7813
A31 Test port 4 coupler
-- Dress panel, overlay – 4-Port (Option 405, 420, and 425) 1 N5222-80036
A35 Test port 3 source attenuator 2 33321-60077
A36 Test port 4 source attenuator
A43 Test port 3 receiver attenuator 2 33321-60078
A44 Test port 4 receiver attenuator
A72 LFE Bias-T combiner - port 3 2 5087-7403
A73 LFE Bias-T combiner - port 4
A70 LFE PC assembly - 2-port 1 N5291-60001
-- Vibration mount (between couplers 1 & 3, and 2 & 4) 2 04670-2725
--
Machine screw, M3 x 8, pan head (to attach A24 mixer brick to mounting plate, bias T
combiner brackets to test set (x4))
15 0515-0372
-- Bias T combiner brackets 2 N5242-00051
--
Machine screw, M4.0 x 10, pan head (2 each to attach the following boards to the
analyzer chassis: A13 13.5 GHz synthesizer board and A8 26.5 GHz source board.)
4 0515-0380
