M8100 Series Arbitrary Waveform Generators Getting Started Guide 33
Introduction 1
M8199B Front Panel Connectors
Table 16 M8199B Front Panel Connectors
The M8199B AWG is controlled by the M8070B software system version
9.5 and above.
This device is ESD-sensitive when operated. The electrostatic discharge
to any part of the module or chassis may cause timing alignment issues
of the channels, which can be mitigated by toggling the sample rate.
Therefore, take necessary anti-static precautions, such as wearing a
grounded wrist strap, to minimize the possibility of electrostatic damage.
Connector Description
Data Out and Data Out Data outputs 1.0 mm
Sync In The Sync In is used to synchronize multiple modules to a common system clock.
It is connected to one of the Sync Out outputs of the M8008A module.
Clk In AWG clock input (quarter-rate). Connect to clock output of M8008A clock
generator module.
Sample Marker Out and Sample Marker Out Differential Marker output to mark individual data samples. Max. output
frequency of 16 GHz.
Sync Marker Out A/B Marker output to generate subrate clocks for example. Max output bandwidth
2 GHz.
