296 Keysight InfiniiVision 3000T X-Series Oscilloscopes User's Guide
18 Frequency Response Analysis
To set up and run the analysis
1 Choose Main Menu > Analyze > Analyze Menu.
2 Click Features; then, select Frequency Response Analysis.
3 Click Features again to enable the feature.
4 Click the Setup & Apply... softkey to open the Frequency Response Analysis
dialog box's tab for setting up the swept frequency response analysis.
DUT
(Transfer Function)
Input Output
Wave
Gen
1
2
3
4
Oscilloscope
