3 Spectrum Analyzer Mode
3.10 TOI Measurement
Command n Return Value
# Item Unit
1 The worst-case Output Intercept Power value dBm
2 The worst-case Output Intermod Point Hz
3 The lower Output Intercept Power value dBm
4 The lower Output Intermod Point Hz
5 The upper Output Intercept Power value dBm
6 The upper Output Intermod Point Hz
2 Returns 13 scalar results, in the following order
# Item Unit
1 The worst-case Output Intermod Point value Hz
2 The worst-case Output Intermod Power
value
dBm
3 The worst-case Output Intercept Power
value
dBm
4 The lower base frequency value Hz
5 The lower base power value dBm
6 The upper base frequency value Hz
7 The upper base power value dBm
8 The lower Output Intermod Point Hz
9 The lower Output Intermod Power value dBm
10 The lower Output Intercept Power value dBm
11 The upper Output Intermod Point Hz
12 The upper Output Intermod Power value dBm
13 The upper Output Intercept Power value dB
:FETCh:TOI:IP3?
:MEASure:TOI:IP3?
:READ:TOI:IP3?
1 Returns the worst-case Output Intercept Power value, in dBm
Backwards Compatibility SCPI
Each of the following commands translates to the equivalent :TOI command.
Backwards Compatibility Command Current Command
:CONFigure:TOINtercept :CONFigure:TOI
:CONFigure:TOINtercept:NDEFault :CONFigure:TOI:NDEFault
:INITiate:TOINtercept :INITiate:TOI
:FETCh:TOINtercept[n]? :FETCh:TOI[n]?
1756 Spectrum Analyzer Mode User's &Programmer's Reference
