Keysight PNA Series User Manual

Cable options (Virginia Diodes Inc.)
Cable option Description
N5262AWCBL-N01 Cables not included for Option 700 or 701 Tx/Rx modules, designed for use with 1.2m cable set.
N5262AWCBL-N05 Cables not included for Option 700 or 701 Tx/Rx modules, designed for use with 5m cable set.
N5262AWCBL-701 1.2m cable set for Option 700 or 701 Tx/Rx modules, for direct connect to 43.5 GHz or higher PNA/PNA-X. Includes ad-
ditional 50 GHz RF cable for high frequency operation. Adapter set N5262AWADP-A01 available for connection to 26.5
GHz PNA and test set.
N5262AWCBL-705 5m cable set for Option 700 or 701 Tx /Rx modules, for direct connection to test set with operation limited to < 26.5 GHz.
Adapter set N5262AWADP-A05 available for connection to 26.5 GHz or >43.5 GHz PNA.
N5262ARCBL-N01 Cables not included for Option 700 or 701 Rx only modules, designed for use with 1.2m cable set.
N5262ARCBL-N05 Cables not included for Option 700 or 701 Rx only modules, designed for use with 5m cable set.
N5262ARCBL-701 1.2m cable set for Option 700 or 701 Rx only modules, for direct connect to 43.5 GHz or higher PNA/PNA-X. Adapter set
N5262ARADP-A01 available for connection to 26.5 GHz PNA and test set.
N5262ARCBL-705 5m cable set for Option 700 or 701 Rx only modules, for direct connection to test set with operation limited to < 26.5 GHz.
Adapter set N5262ARADP-A05 available for connection to 26.5 GHz or >43.5 GHz PNA.
N5262AWCBL-201 1.2m cable set for Option 700 or 701 Tx/Rx modules, for direct connect to 26.5 GHz PNA/PNA-X.
N5262AWCBL-205 5m cable set for Option 700 or 701 Tx/Rx modules, for direct connect to >43.5 GHz PNA/PNA-X.
N5262AWCBL- 401 1.2m cable set for Option 700 or 701 Tx/Rx modules, for direct connect to 43.5 GHz or higher PNA/PNA-X. Does NOT
include 50 GHz RF cable for high frequency operation.
N5262AWCBL- 40 5 5m cable set for Option 700 or 701 Tx /Rx modules, for direct connection to 43.5 GHz or higher PNA/PNA-X with opera-
tion limited to < 26.5 GHz.
N5262AWCBL- 501 1.2m cable set for Option 700 or 701 Tx/Rx modules, for connect to test set
N5262ARCBL- 201 1.2m cable set for Option 700 or 701 Rx modules, for direct connect to 26.5 GHz PNA/PNA-X.
N5262ARCBL - 205 5m cable set for Option 700 or 701 Rx modules, for direct connect to >43.5 GHz PNA/PNA-X.
N5262ARCBL-401 1.2m cable set for Option 700 or 701 Rx modules, for direct connect to 43.5 GHz or higher PNA/PNA-X.
N5262A RCBL-405 5m cable set for Option 700 or 701 Rx modules, for direct connection to 43.5 GHz or higher PNA/PNA-X with operation
limited to < 26.5 GHz.
N5262ARCBL- 501 1.2m cable set for Option 700 or 701 Rx modules, for direct connect to test set.
Power supply option (Virginia Diodes Inc.)
Option number Description
N5262VDI-175 VDI-175 power supply for VDI Modules
Notes
Must be ordered with N5262AWxx. See table above for product option numbers.
Banded Solution Conguration
Millimeter-wave calibration kits (Virginia Diodes Inc.)
Waveguide ange Frequency GHz Calibration kit
WR15 50 to 75 N5262AC15
WR12 60 to 90 N5262AC12
WR10 75 to 110 N5262AC10
WR8.0 90 to 140 N5262AC08
WR6.5 110 to 170 N5262AC06
WR5.1 140 to 220 N5262AC05
WR3.4 220 to 325 N5262AC03
Adapter kits for use with N5262AWCBL-701 and N5262AWCBL-705
Adapter kit option Description
N5262AWADP-A01 Adapter set for N5262AWCBL-701 to connect to 26.5 GHz PNA or controller
N5262AWADP-A05 Adapter set for N5262AWCBL-705 to connect to 26.5 GHz or >43.5 GHz PNA
N5262ARADP-A01 Adapter set for N5262ARCBL-701 to connect to 26.5 GHz PNA or controller
N5262ARADP-A05 Adapter set for N5262ARCBL-705 to connect to 26.5 GHz or >43.5 GHz PNA
19 | Keysight | Antenna Test – Selection Guide

Keysight PNA Series Specifications

General

Number of Ports	2, 4
Impedance	50 Ω
Output Power Range	-55 dBm to +13 dBm (varies by model)
Dimensions	Varies by model
Weight	Varies by model
Power Requirements	100-240 VAC, 50/60 Hz
Storage Temperature	-40°C to 70°C
