Keysight PNA Series User Manual

Waveguide ange Frequency GHz Standard transmission/reection modules
Standard transmission/reection modules with
25 dB mechanical attenuator
WR15 50-75 N5262AW15-700 N5262AW15-701
WR10
75-110 N5262AW10-700 N5262AW10-701
WR8.0 90-140 N5262AW08-700 N5262AW08-701
WR6.0 110-170 N5262AW06-700 N5262AW06-701
WR5.1 140 - 220 N5262AW05-700 N5262AW05-701
WR3.4 220 -325 N5262AW03-700 N5262AW03-701
WR2.2 325-500 N5262AW02-700 N5262AW02-701
WR1.5 500 - 750 N5256AW01-700 N5256AW01-701
WR1.0 750 – 1100 N5262AW01-700 No Attenuator Option
Notes
1. Each product number includes a single frequency extender that supports all PNA/PNA-X and test sets.
2. Add required power supply and cable option for the frequency extenders.
3. For full 2-Port S-parameter measurements order quantity 2 of the Tx/Rx modules listed above.
4. When used with N5261A or N5262A test set controller, add a power supply and cable options.
5. Options 700 /701 WR1.5 extenders are not supported for use with the N5261A/62A.
Banded Solution Conguration
Millimeter-wave calibration kits (OML Inc.)
Waveguide ange Frequency GHz Calibration kit
WR15 50 - 75 V11644A
WR12 60 - 90 N5260AC12
WR10 75 - 110 W11644A
WR08 90 - 140 N5260AC08
WR06 110 - 170 N5260AC06
WR05 140 - 220 N5260AC05
WR03 220 - 325 N5260AC03
WR02.2 325 - 500 N5260AC02
Extended WR12 56 - 94 N5260AC12
Banded waveguide transmission reection modules (Virginia Diodes Inc.)
Waveguide ange Frequency GHz Standard receiver only modules
High sensitivity receive only module with external
xed attenuator
WR15 50-75 N5262AR15-700 N5262AR15-701
WR10 75-110 N5262AR10-700 N5262AR10-701
WR8.0 90-140 N5262AR08-700 N5262AR08-701
WR6.0 110-170 N5262AR06-700 N5262AR06-701
WR5.1 140 - 220 N5262AR05-700 N5262AR05-701
WR3.4 220 -325 N5262AR03-700 N5262AR03-701
WR2.2 325-500 N5262AR02-700 N5262AR02-701
WR1.5 500 - 750 N5256AR01-700 N5256AR01-701
WR1.0 750 - 1100 N5262AW01-700 Not Available
Notes
1. Each product number includes a single frequency extender only.
2. Add required power supply and cable options at time of order.
3. The above are receiver only and require a Tx/Rx module for 1 path 2-port S-parameter measurement capability.
4. When used with N5261A or N5262A test set controller, add a power supply and cable options.
5. Options 700 /701 WR1.5 extenders are not supported for use with the N5261A/62A.
Banded waveguide receive only modules (Virginia Diodes Inc.)
18 | Keysight | Antenna Test – Selection Guide

Keysight PNA Series Specifications

General

Number of Ports	2, 4
Impedance	50 Ω
Output Power Range	-55 dBm to +13 dBm (varies by model)
Dimensions	Varies by model
Weight	Varies by model
Power Requirements	100-240 VAC, 50/60 Hz
Storage Temperature	-40°C to 70°C
