Sources (continued)
Select a transmit source from the following table:
Table 5. Sources
Source Frequency range Output power at Fmax
High power (Option 1EA)
at Fmax (typical)
PSG analog signal generators
E8257D-520 250 kHz - 20 GHz +15 dBm +23 dBm
E8257D-532 250 kHz - 32 GHz +11 dBm +17 dBm
E8257D-540 250 kHz - 40 GHz +11 dBm +17 dBm
E8257D-550 250 kHz - 50 GHz +5 dBm +14 dBm
E8257D-567 250 kHz - 67 GHz +5 dBm +14 dBm
MXG analog signal generators
N5183A-520 100 kHz - 20 GHz +11 dBm +18 dBm
N5183A-532 100 kHz - 32 GHz +7 dBm +12 dBm
N5183A-540 100 kHz - 40 GHz +7 dBm +12 dBm
PSG vector signal generators
E8267D-520 250 kHz - 20 GHz +18 dBm (+22 dBm) NA
E8267D-532 250 kHz - 32 GHz +14 dBm (+18 dBm) NA
E8267D-544 250 kHz - 44 GHz +10 (+13 dBm) NA
For more information on MXG and PSG signal generators visit:
www.keysight.com/nd/N5183A
www.keysight.com/nd/PSG
For data sheets and additional details visit: www.keysight.com/nd/na
53 | Keysight | Antenna Test – Selection Guide

Keysight PNA Series Specifications

General

Number of Ports	2, 4
Impedance	50 Ω
Output Power Range	-55 dBm to +13 dBm (varies by model)
Dimensions	Varies by model
Weight	Varies by model
Power Requirements	100-240 VAC, 50/60 Hz
Storage Temperature	-40°C to 70°C
