Keysight U3606A - Performing Voltage Measurements

Digital Multimeter Operation 2
Making Measurements
U3606A User’s and Service Guide 25
Performing voltage measurements
Making the connections
Connect the test leads as shown below:
Figure 2-1 Terminal connections for voltage measurements
+
–
AC or DC
voltage source
NOTE
• The U3606A will automatically select a suitable range for voltage
measurements by default (autoranging). To manually select a range,
see “Selecting a Range” on page 54 for more information.
• The U3606A resolution is set to 5½ digits by default. To change the
resolution, see “Setting the Resolution” on page 55 for more
information.
