Keysight U3606A - Table 6-2 Valid Gain Adjustment Input Values

6 Calibration Procedures
Adjustments procedures
198 U3606A User’s and Service Guide
Valid gain adjustment input values
Gain adjustment can be accomplished using the following input values.
Table 6 - 2 Valid gain adjustment input values
Function Range
Valid amplitude
input values
Page
DC voltage
• 100 mV
• 1 V
• –1 V
• 10 V
• 100 V
• 1000 V
0.9 to 1.1 × full scale page 199
AC voltage
• 10 mV
• 100 mV
• 1 V
• 10 V
• 100 V
• 750 V
0.9 to 1.1 × full scale page 201
Frequency Autorange/1 kHz
Input ¥ 100 mV
rms
,
900 Hz to 1100 Hz
page 202
Resistance
(2-wire)
• 100 Ω
• 1 kΩ
• 10 kΩ
• 100 kΩ
• 1 MΩ
• 10 MΩ
0.9 to 1.1 × full scale page 203
DC current
• 10 mA
• 100 mA
• 1000 mA
0.9 to 1.1 × full scale page 205
