765
Maintenance
Fuse Name Fuse rating Circuit Protected
TCU 15A
Engine Room Junction Block(Back-Up Lamp Switch), Automatic Transmission Shift Lever, Position
Switch, Stop Lamp Switch
P/WINDOW LH 25A Power Window Main Switch
SPARE1 25A Spare
FOG LAMP REAR 10A -
HEATED STEERING 15A Steering Wheel Heated
TAIL LAMP LH 7.5A
Head Lamp Left Handle side, License Lamp Left Handle side, Rear Combination Lamp (OUT) Left
Handle side, Rear Combination Lamp (IN) Left Handle side, Glove Box Lamp
MODULE3 7.5A
Front Seat Warmer Control Module, Audio, Electro Chromic Mirror, Air Conditioner Control Module,
Audio/Video & Navigation Head Unit, Clock Spring, Automatic Transmission Shift Lever indicator
ABS 7.5A Data Link Connector, ESC (Electronic Stability Control) Module
BRAKE SWITCH 10A Stop Lamp Switch, Smart Key Control Module
SPARE4 15A Spare
FOG LAMP FRONT 15A Front Fog Lamp Relay
A/C1 7.5A Engine Room Junction Block(Blower Relay), Air Conditioner Control Module
MODULE5 10A
Engine Room Junction Block(Head Lamp Relay, Head Lamp Hi Relay), Rain Sensor, Sunroof Motor,
Front Seat Warmer Control Module, Driver Safety Power Window Module
MODULE7 10A TPMS (Tire Pressure Monitoring System) Unit
ECU 10A ECM (Engine Control Module)/PCM (Power train Control Module)
