Fuse Name Fuse rating Circuit Protected
SUNROOF 15A Sunroof Motor
IMMO 10A Immobilizer Module
MODULE6 10A Key Solenoid
SPARE2 10A Spare
MODULE4 7.5A SLM (Seat Belt & Lighting Module), BCM (Body Control Module), Smart Key Control Module
SMART KEY2 10A Immobilizer Module, Smart Key Control Module
AIR BAG 10A ACU (Airbag Control Unit), Passenger Occupant Detection Sensor
MODULE1 7.5A BCM (Body Control Module), SLM (Seat Belt & Lighting Module), Key Interlock
SMART KEY 25A Smart Key Control Module
A/C2 7.5A Blower Module
WIPER RR 15A Multifunction Switch, Rear Wiper Motor, Rear Wiper Relay
WIPER FRT 25A Multifunction Switch, Front Wiper Motor, Engine Room Junction Block(Wiper Low Relay)
ACC 10A
Power Outlet Relay, BCM (Body Control Module), SLM (Seat Belt & Lighting Module), Audio, Key Interlock,
Audio/Video & Navigation Head Unit, USB Charging Connector, Power Outside Mirror Switch, Smart Key
Control Module
