Fuse Name Fuse rating Circuit Protected
SPARE3 20A Spare
A/BAG IND 7.5A Instrument Cluster, Center Fascia Switch
CLUSTER 7.5A Instrument Cluster
MDPS 7.5A MDPS (Motor Driven Power Steering) Unit
AUDIO 20A Audio, Audio/Video & Navigation Head Unit
ROOM LAMP 10A
Room Lamp Relay, Glove Box Lamp, Overhead Console Lamp, Air Conditioner Control Module, SLM (Seat
Belt & Lighting Module), BCM (Body Control Module), Auto Light & Photo Sensor, TPMS (Tire Pressure
Monitoring System) Unit, Front Vanity Lamp Left Handle side/Right Handle side, Instrument Cluster, Data
Link Connector, Room Lamp, Trunk Room Lamp
