Maintenance
Engine room compartment fuse panel
Fuse Name Fuse rating Circuit Protected
MDPS 80A MDPS (Motor Driven Power Steering) Unit
ALT 150A Fuse - ABS1, BAS2, BLOWER, REAR HEATED
REAR HEATED 40A Instrument Panel Junction Block (Rear Defogger Relay)
ABS1 40A ESC (Electronic Stability Control) Module
ABS2 40A ESC (Electronic Stability Control) Module
BLOWER 40A Blower Relay
WIPER 10A
[With BCM (Body Control Module)] Front Wiper Motor, Multifunction Switch,
[With Out BCM (Body Control Module)] Wiper Low Relay
ECU4 15A ECM (Engine Control Module)/PCM (Power train Control Module)
SENSOR 10A
Oil Control Valve #1/#2, Cooling Fan1/2 Relay, Oxygen Sensor (Up), Oxygen Sensor (Down), Variable
Intake Solenoid Valve, Air Conditioner Relay, Purge Control Solenoid Valve, Canister Close Valve
ECU2 15A ECM (Engine Control Module)/PCM (Power train Control Module)
ECU3 20A ECM (Engine Control Module)/PCM (Power train Control Module)
HEAD LAMP RH 10A Head Lamp Right Handle side
HEAD LAMP LH 10A Head Lamp Left Handle side
IGN COIL 20A Ignition Coil #1~#4
ECU5 15A ECM (Engine Control Module)/PCM (Power train Control Module), Fuel Pump Relay, Injector #1~#4
