Maintenance
707
Fuse Name Fuse rating Circuit Protected
B/UP LAMP 10A Back-Up Lamp Switch
B+1 40A
Instrument Panel Junction Block (Fuse - DRL2, FOGLAMP FRONT, STOP LAMP, MODULE6, Power
Connector (AUDIO, ROOM LAMP))
B+2 50A
Instrument Panel Junction Block (Fuse - IMMO, SMART KEY, BRAKE SWITCH, SAFETY P/WINDOW,
S/HEATER, SUNROOF, Power Window Relay)
IG2 40A Ignition Switch, IG2 Relay, Start Relay
COOLING FAN 40A Cooling Fan1/2 Relay
ECU1 30A Fuse - ECU3, ECU4, Main Relay
HEAD LAMP 20A Head Lamp Relay
H/LAMP HI 20A
With CANADA DRL : SLM(Seat Belt & Lighting Module) or BCM(Body Control Module)
Without CANADA DRL : Head Lamp HI Relay
FUEL PUMP 20A Fuel Pump Relay
HORN 15A Horn Relay/ Burglar Alarm Horn Relay
A/C 10A Air Conditioner Relay
AMS 10A Battery Sensor
B+3 40A Instrument Panel Junction Block (Fuse - T/SIGNAL LAMP, DOOR LOCK, Tail Lamp Relay)
IG1 40A
Start Relay, [With Smart Key] IG1 Relay, ACC Relay,
[With Out Smart Key] Ignition Switch
POWER OUTLET 40A Instrument Panel Junction Block (Power Outlet Relay)
