Table 6-6. Selector Valve Dimensions
Valve Size
Assembly Part
Number
Dimensions
Nipple Connector
ABCDEFGHJ
1/2 in. 38-509848-001 5.53 2.77 2.14 6.97 1.55 2.73 2.77 1.14 0.50 38-509813-001
3/4 in. 38-509848-002 6.24 3.12 2.46 7.29 1.92 3.50 3.27 1.42 0.88 38-509813-001
1 in. 38-509848-003 6.24 3.12 2.46 7.52 1.92 3.60 3.27 1.42 0.88 38-509813-001
1¼ in. 38-509848-004 8.24 4.14 2.80 8.65 2.10 3.93 3.72 1.67 1.00 38-509813-001
1½ in. 38-509848-005 9.74 4.87 3.05 9.35 2.47 4.55 4.18 1.95 1.25 38-509813-001
2 in. 38-509848-006 10.57 5.28 3.29 10.02 2.66 4.94 4.84 2.20 1.50 38-509814-001
Note: The Selector Valve Assembly part numbers listed only include the Valve, Actuator and Reset Handle.
Table 6-7. Selector Valve Assembly Replacement Parts
Part Number Description
38-509848-001 1/2" Valve, Actuator and Reset Handle Only
38-509848-002 3/4" Valve, Actuator and Reset Handle Only
38-509848-003 1" Valve, Actuator, and Reset Handle Only
38-509848-004 1¼" Valve, Actuator and Reset Handle Only
38-509848-005 1½" Valve, Actuator and Reset Handle Only
38-509848-006 2" Valve, Actuator and Reset Handle Only
38-509837-001 Solenoid, 24 Vdc, 3-Way, Weatherproof
38-509813-001 Nipple Connector 1/8" x 1/4" NPT (1/2" to 1½" Valves)
38-509814-001 Nipple Connector 1/4" x 1/4" NPT (2" Valves Only)
38-509858-001 Closing Instructions Nameplate
