Kidde Fire Systems Argonite User Manual

6-21
July 2004
Argonite
®
Engineered Fire Suppression System
38-KFSARG-000
Table 6-15. Cylinder Rack Kits, One Row/One Side
Item
Number
Description
2 Cylinder
P/N 38-109809-001
3 Cylinder
P/N 38-109810-001
4 Cylinder
P/N 38-109811-001
5 Cylinder
P/N 38-109812-001
6 Cylinder
P/N 38-109813-001
7 Cylinder
P/N 38-109814-001
Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number
1 Header 1 38-503075-001 1 38-503075-002 1 38-503075-003 1 38-503075-004 1 38-503075-005 1 38-503075-002
2 3/8 in. - 16 in. x 1 in. HHDCS 2 38-503076-001 2 38-503076-001 2 38-503076-001 2 38-503076-001 2 38-503076-001 4 38-503076-001
3 3/8 in. Lockwasher 2 38-503077-001 2 38-503077-001 2 38-503077-001 2 38-503077-001 2 38-503077-001 4 38-503077-001
4 3/8 in. - 16 HEX Nut 2 38-503078-001 2 38-503078-001 2 38-503078-001 2 38-503078-001 2 38-503078-001 4 38-503078-001
5 U-Bolt 2 38-503079-003 2 38-503079-003 2 38-503079-003 2 38-503079-003 2 38-503079-003 3 38-503079-002
6 U-Bolt Lockwasher 4 38-503080-001 4 38-503080-001 4 38-503080-001 4 38-503080-001 4 38-503080-001 6 38-503080-002
7 Upright 2 38-503081-001 2 38-503081-001 2 38-503081-001 2 38-503081-001 2 38-503081-001 4 38-503081-001
8 Rail 1 38-503074-001 1 38-503074-002 1 38-503074-003 1 38-503074-004 1 38-503074-005 1 38-503074-003
9 1/2 in. -13 Channel Nut 5 38-503082-001 6 38-503082-001 7 38-503082-001 8 38-503082-001 9 38-503082-001 15 38-503082-001
10 1/2 in. Lockwasher 12 38-503083-001 14 38-503083-001 16 38-503083-001 18 38-503083-001 20 38-503083-001 30 38-503083-001
11 Stud (Threaded Rod) 3 38-503084-001 4 38-503084-001 5 38-503084-001 6 38-503084-001 7 38-503084-001 9 38-503084-001
12 1/2 in. Flat Washer 4 38-503085-001 6 38-503085-001 8 38-503085-001 10 38-503085-001 12 38-503085-001 14 38-503085-001
13 1/2 in. - 13 HEX Nut 10 38-503086-001 12 38-503086-001 14 38-503086-001 16 38-503086-001 18 38-503086-001 26 38-503086-001
14 Cylinder Strap 2 38-503087-001 3 38-503087-001 4 38-503087-001 5 38-503087-001 6 38-503087-001 7 38-503087-001
15 Brace, Left Side 1 38-503088-001 1 38-503088-001 1 38-503088-001 1 38-503088-001 1 38-503088-001 1 38-503088-001
16 Brace, Right Side 1 38-503089-001 1 38-503089-001 1 38-503089-001 1 38-503089-001 1 38-503089-001 1 38-503089-001
17 1/2 in. -13 x 1 in. HHDCS 6 38-503090-001 6 38-503090-001 6 38-503090-001 6 38-503090-001 6 38-503090-001 13 38-503090-001
181/2 in. -13 x 1½ in. HHDCS––––––––––238-503091-001
19 Rail Support – – – – – – – – – – 2 38-503092-001
20Rail ––––––––––138-503074-002
21 Header – – – – – – – – – – 1 38-503075-003
Item
Number
Description
8 Cylinder
P/N 38-109815-001
9 Cylinder
P/N 38-109816-001
10 Cylinder
P/N 38-109817-001
11 Cylinder
P/N 38-109818-001
12 Cylinder
P/N 38-109819-001
Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number
1 Header 2 38-503075-003 1 38-503075-003 2 38-503075-004 1 38-503075-004 2 38-503075-005
2 3/8 in. - 16 in. x 1 in. HHDCS 4 38-503076-001 4 38-503076-001 4 38-503076-001 4 38-503076-001 4 38-503076-001
3 3/8 in. Lockwasher 4 38-503077-001 4 38-503077-001 4 38-503077-001 4 38-503077-001 4 38-503077-001
4 3/8 in. - 16 HEX Nut 4 38-503078-001 4 38-503078-001 4 38-503078-001 4 38-503078-001 4 38-503078-001
5 U-Bolt 3 38-503079-002 3 38-503079-002 3 38-503079-002 3 38-503079-001 3 38-503079-001
6 U-Bolt Lockwasher 6 38-503080-002 6 38-503080-002 6 38-503080-002 6 38-503080-002 6 38-503080-002
7 Upright 4 38-503081-001 4 38-503081-001 4 38-503081-001 4 38-503081-001 4 38-503081-001
8 Rail 2 38-503074-003 1 38-503074-003 2 38-503074-004 1 38-503074-004 2 38-503074-005
9 1/2 in. -13 Channel Nut 15 38-503082-001 16 38-503082-001 17 38-503082-001 18 38-503082-001 19 38-503082-001
10 1/2 in. Lockwasher 32 38-503083-001 34 38-503083-001 36 38-503083-001 38 38-503083-001 40 38-503083-001
11 Stud (Threaded Rod) 9 38-503084-001 10 38-503084-001 11 38-503084-001 12 38-503084-001 13 38-503084-001
12 1/2 in. Flat Washer 16 38-503085-001 18 38-503085-001 20 38-503085-001 22 38-503085-001 24 38-503085-001
13 1/2 in. - 13 HEX Nut 28 38-503086-001 30 38-503086-001 32 38-503086-001 34 38-503086-001 36 38-503086-001
14 Cylinder Strap 8 38-503087-001 9 38-503087-001 10 38-503087-001 11 38-503087-001 12 38-503087-001
15 Brace, Left Side 1 38-503088-001 1 38-503088-001 1 38-503088-001 1 38-503088-001 1 38-503088-001
16 Brace, Right Side 1 38-503089-001 1 38-503089-001 1 38-503089-001 1 38-503089-001 1 38-503089-001
17 1/2 in. -13 x 1 in. HHDCS 12 38-503090-001 12 38-503090-001 12 38-503090-001 12 38-503090-001 12 38-503090-001
18 1/2 in. -13 x 1½ in. HHDCS 2 38-503091-001 2 38-503091-001 2 38-503091-001 2 38-503091-001 2 38-503091-001
19 Rail Support 2 38-503092-001 2 38-503092-001 2 38-503092-001 2 38-503092-001 2 38-503092-001
20 Rail – – 1 38-503074-004 – – 1 38-503074-005 – –
21 Header – – 1 38-503075-004 – – 1 38-503075-005 – –
