Kidde Fire Systems Argonite

6-25
July 2004
Argonite
®
Engineered Fire Suppression System
38-KFSARG-000
Table 6-19. Cylinder Rack Kits, Two Rows/One Side
Item
Number
Description
3 or 4 Cylinders
P/N 38-109831-001
5 or 6 Cylinders
P/N 38-109832-001
7 or 8 Cylinders
P/N 38-109833-001
9 or 10 Cylinders
P/N 38-109834-001
11 or 12 Cylinders
P/N 38-109835-001
Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number
1 Header 1 38-503075-001 1 38-503075-002 1 38-503075-003 1 38-503075-004 1 38-503075-005
2 3/8 in. - 16 in. x 1 in. HHDCS 2 38-503076-001 2 38-503076-001 2 38-503076-001 2 38-503076-001 2 38-503076-001
3 3/8 in. Lockwasher 2 38-503077-001 2 38-503077-001 2 38-503077-001 2 38-503077-001 2 38-503077-001
4 3/8 in. - 16 HEX Nut 2 38-503078-001 2 38-503078-001 2 38-503078-001 2 38-503078-001 2 38-503078-001
5 U-Bolt 2 38-503079-003 2 38-503079-002 2 38-503079-002 2 38-503079-002 2 38-503079-001
6 U-Bolt Lockwasher 2 38-503080-001 4 38-503080-002 4 38-503080-002 4 38-503080-002 4 38-503080-002
7 Upright 2 38-503081-001 2 38-503081-001 2 38-503081-001 2 38-503081-001 2 38-503081-001
8 Rail 1 38-503074-001 1 38-503074-002 1 38-503074-003 1 38-503074-004 1 38-503074-005
9 1/2 in. -13 Channel Nut 5 38-503082-001 6 38-503082-001 7 38-503082-001 8 38-503082-001 9 38-503082-001
10 1/2 in. Lockwasher 17 38-503083-001 19 38-503083-001 21 38-503083-001 23 38-503083-001 25 38-503083-001
11 Stud (Threaded Rod) 3 38-503084-002 4 38-503084-002 5 38-503084-002 6 38-503084-002 7 38-503084-002
12 1/2 in. Flat Washer 5 38-503085-001 7 38-503085-001 9 38-503085-001 11 38-503085-001 13 38-503085-001
13 1/2 in. - 13 HEX Nut 15 38-503086-001 17 38-503086-001 19 38-503086-001 21 38-503086-001 23 38-503086-001
14 Cylinder Strap 2 38-503087-001 3 38-503087-001 4 38-503087-001 5 38-503087-001 6 38-503087-001
15 Brace, Left Side 1 38-503088-001 1 38-503088-001 1 38-503088-001 1 38-503088-001 1 38-503088-001
16 Brace, Right Side 1 38-503089-001 1 38-503089-001 1 38-503089-001 1 38-503089-001 1 38-503089-001
17 1/2 in. -13 x 1 in. HHDCS 10 38-503090-001 10 38-503090-001 10 38-503090-001 10 38-503090-001 10 38-503090-001
18 Manifold Mounting Bracket 2 38-503093-001 2 38-503093-001 2 38-503093-001 2 38-503093-001 2 38-503093-001
19 Stud (Short Rod) 1 38-503084-001 1 38-503084-001 1 38-503084-001 1 38-503084-001 1 38-503084-001
Item
Number
Description
13 or 14 Cylinders
P/N 38-109836-001
15 or 16 Cylinders
P/N 38-109837-001
17 or 18 Cylinders
P/N 38-109838-001
19 or 20 Cylinders
P/N 38-109839-001
21 or 22 Cylinders
P/N 38-109840-001
23 or 24 Cylinders
P/N 38-109841-001
Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number Qty. Part Number
1 Header 1 38-503075-002 2 38-503075-003 1 38-503075-003 2 38-503075-004 1 38-503075-004 2 38-503075-005
2 3/8 in. - 16 in. x 1 in. HHDCS 4 38-503076-001 4 38-503076-001 4 38-503076-001 4 38-503076-001 4 38-503076-001 4 38-503076-001
3 3/8 in. Lockwasher 4 38-503077-001 4 38-503077-001 4 38-503077-001 4 38-503077-001 4 38-503077-001 4 38-503077-001
4 3/8 in. - 16 HEX Nut 4 38-503078-001 4 38-503078-001 4 38-503078-001 4 38-503078-001 4 38-503078-001 4 38-503078-001
5 U-Bolt 3 38-503079-001 3 38-503079-001 3 38-503079-001 3 38-503079-001 3 38-503079-001 3 38-503079-001
6 U-Bolt Lockwasher 6 38-503080-002 6 38-503080-002 6 38-503080-002 6 38-503080-002 6 38-503080-002 6 38-503080-002
7 Upright 4 38-503081-001 4 38-503081-001 4 38-503081-001 4 38-503081-001 4 38-503081-001 4 38-503081-001
8 Rail 1 38-503074-003 2 38-503074-003 1 38-503074-003 2 38-503074-004 1 38-503074-004 2 38-503074-005
9 1/2 in. -13 Channel Nut 14 38-503082-001 15 38-503082-001 16 38-503082-001 17 38-503082-001 18 38-503082-001 19 38-503082-001
10 1/2 in. Lockwasher 37 38-503083-001 39 38-503083-001 41 38-503083-001 43 38-503083-001 45 38-503083-001 47 38-503083-001
11 Stud (Threaded Rod) 8 38-503084-002 9 38-503084-002 10 38-503084-002 11 38-503084-002 12 38-503084-002 13 38-503084-002
12 1/2 in. Flat Washer 15 38-503085-001 17 38-503085-001 19 38-503085-001 21 38-503085-001 23 38-503085-001 25 38-503085-001
13 1/2 in. - 13 HEX Nut 31 38-503086-001 33 38-503086-001 35 38-503086-001 37 38-503086-001 39 38-503086-001 41 38-503086-001
14 Cylinder Strap 7 38-503087-001 8 38-503087-001 9 38-503087-001 10 38-503087-001 11 38-503087-001 12 38-503087-001
15 Brace, Left Side 1 38-503088-001 1 38-503088-001 1 38-503088-001 1 38-503088-001 1 38-503088-001 1 38-503088-001
16 Brace, Right Side 1 38-503089-001 1 38-503089-001 1 38-503089-001 1 38-503089-001 1 38-503089-001 1 38-503089-001
17 1/2 in. -13 x 1 in. HHDCS 18 38-503090-001 18 38-503090-001 18 38-503090-001 18 38-503090-001 18 38-503090-001 18 38-503090-001
18 Manifold Mounting Bracket 3 38-503093-001 3 38-503093-001 3 38-503093-001 3 38-503093-001 3 38-503093-001 3 38-503093-001
19 Stud (Short Rod) 1 38-503084-001 1 38-503084-001 1 38-503084-001 1 38-503084-001 1 38-503084-001 1 38-503084-001
20 1/2 in. -13 x 1½ in. HHDCS 2 38-503091-001 2 38-503091-001 2 38-503091-001 2 38-503091-001 2 38-503091-001 2 38-503091-001
21 Rail Support 2 38-503092-001 2 38-503092-001 2 38-503092-001 2 38-503092-001 2 38-503092-001 2 38-503092-001
22 Rail 1 38-503074-002 – – 1 38-503074-004 – – 1 38-503074-005 – –
23 Header 1 38-503075-003 – – 1 38-503075-004 – – 1 38-503075-005 – –
