Kidde VS4 User Manual

Chapter 2: Front panel programming
110 P/N 3102351-EN • REV 005 • ISS 28DEC18
Zone: When a device is a member of a zone, only the zone information is
reported or transmitted. Device information is not reported or transmitted. This
setting uses zone event notification settings for reporting events. Make sure the
zone event notification settings are correct. See “Loop event programming” on
page 120.
Event: Only the event type (alarm, supervisory, trouble, etc.) is reported or
transmitted, no device or zone information. This setting uses the CMS event
notification settings for reporting events. Make sure the event notification
settings are correct. See “Central monitoring station device programming” on
page 106.
Tone wait seconds
Set tone wait to Off or 1 to 30 seconds. Specifies how long the dialer waits to
get
a dial tone.
Call disconnect seconds
Set call disconnect to Off or 1 to 45 seconds. Specifies the length of time the
dialer seizes the line (to disconnect parallel devices) before attempting to dial
out.
Test frequency hours
Set test frequency to 0 to 240 hours. Specifies how often the dialer performs a
test call. The default setting is 6 hours to comply with agency requirements. See
“UL/ULC programming requirements” on page 35 for details.
Test time
Set the test time to the desired time of day for running the test.
Rings to answer
Set rings to answer to Off or 1 to 15 rings. Specifies how many rings before the
dialer answers incoming calls.
Ring type
Set ring type to Any or Normal. Specifies the type of ring expected when an
incoming call is received.
Callback
Select Enabled or Disabled to enable or disable callback security. With callback
security enabled, the dialer will answer an incoming call, and then hang up and
redial the callback number in an attempt to connect to the PC running the
configuration utility. Use this feature to increase security and to limit your
connect to only the PC at the preprogrammed number.
Line 1 and 2
Dialing:
Cut duration/supervision
Program line 1 options, and then program line 2 options. When you have
finished programming each line, choose Save.
Select Tone or Pulse dialing.
Set the cut duration/supervision to Off or 10 to 120 seconds. Specifies the length
of time a phone line trouble is detected before reporting the trouble.
Callback number
Enter the callback phone number (up to 20 digits). This specifies the phone
number that is used for call back.
Note: Select Off to set to 0 wait time, no frequencies, or no occurrence.
To program the dialer:
1. Display the panel configuration options menu. See “Panel programming” on page 102.
2. Choose CMS Device.
3. Choose Dialer.
4. Program the dialer using Table 33 on page 109. For dialer default settings, see “Factory
default settings” on page 42.
5. When you have finished programming each option, choose Save.
