Chapter 3: System operation
P/N 3102351-EN • REV 005 • ISS 28DEC18 145
ID
Event description
100
NAC 2 trouble: An open or short was
detected on NAC 2 or there is a problem
with the EOL
101
NAC 3 trouble: An open or short was
detected on NAC 3 or there is a problem
with the EOL
102
NAC 4 trouble: An open or short was
detected on NAC 4 or there is a problem
with the EOL
103
Printer trouble: The printer is either offline,
out of paper, or disconnected
104
Annunciator 1 trouble: An open or short
was detected on annunciator 1
105
Annunciator 2 trouble: An open or short
was detected on annunciator 2
106
Annunciator 3 trouble: An open or short
was detected on annunciator 3
107
Annunciator 4 trouble: An open or short
was detected on annunciator 4
108
Annunciator 5 trouble: An open or short
was detected on annunciator 5
109
Annunciator 6 trouble: An open or short
was detected on annunciator 6
110
Annunciator 7 trouble: An open or short
was detected on annunciator 7
111
Annunciator 8 trouble: An open or short
was detected on annunciator 8
112
Zone 1 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone1)
113
Zone 2 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected on
zone 2)
114
Zone 3 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 3)
115
Zone 4 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 4)
ID
Event description
116
Zone 5 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 5)
117
Zone 6 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 6)
118
Zone 7 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 7)
119
Zone 8 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 8)
120
Zone 9 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 9)
121
Zone 10 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 10)
122
Zone 11 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 11)
123
Zone 12 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 12)
124
Zone 13 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 13)
125
Zone 14 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 14)
126
Zone 15 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 15)
127
Zone 16 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 16)
128
Zone 17 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 17)
129
Zone 18 (active, trouble, disable, prealarm,
alarm verify, maintenance alert, or test was
detected in zone 18)
