48 Specifications TOS8030
9.2 Other Functions
9.3 General Specifications
Remote control
Connector 5-pin DIN connector on the rear panel
Control available Start/stop of testing
Optional devices connectable
Remote control boxes: RC01-TOS and RC02-TOS
High-voltage test probes: HP01A-TOS and HP02A-TOS
Signal I/O
Connector 14-pin screw-less terminal on the rear panel
Status signal output
Output of a READY signal / H.V ON signal / PASS signal / FAIL signal
/ PROTECTION signal
Make-contact signal (contact rating: 1 A/30 Vdc)
INTERLOCK input terminal A PROTECTION state is invoked when the terminals are open.
Environment
Operation environment Indoor use, Overvoltage Category II
Specifications-
assured range
Temperature 5°C to 35°C
Relative humidity 20% to 80% (with no dew condensation)
Operating range
Temperature 0°C to 40°C
Relative humidity 20% to 80% (with no dew condensation)
Storage range
Temperature -40°C to 70°C
Relative humidity 90% or less (with no dew condensation)
Altitude Up to 2000 m
AC input
Nominal input rating
(Input voltage range)
220 V (200 V to 240 V) or 100 V (90 V to 110 V),
50 Hz or 60 Hz
Power consumption
At no-load
(in READY state)
10 VA or less
At rated load 50 VA maximum
Insulation resistance
AC INPUT to
chassis
30 MΩ or more (at 500 Vdc)
Withstand voltage
AC INPUT to
chassis
10 mA or less when 1390 Vac is applied for 2 seconds
Earth continuity 25 Aac/0.1 Ω or less
Dimensions (largest section) 160 (170) W x 132 (155) H x 230 (270) D mm
Weight Approx. 6 kg
Accessories
• High-voltage test leads TL01-TOS (approx. 1.5 m): 1 set
• Power cord: 1
• INTERLOCK jumper: 1
• Operation Manual: 1 copy
