Kinco CD620 - Page 14

14
interface (-)
X2
24VS/GNDS
Logic power supply:24 V ± 15% ,>0.5A
24VB/GNDB
Power supply for brake ,DC18~30V 2A
BR+/BR-
Brake interface
X3
CD422
U/V/W/PE
Motor cable interface
L/N
Main power supply（Single-phase AC220V）
RB+/RB-
Braking resistor interface
CD432/CD622
U/V/W/PE
Motor cable interface
X5
CD422
CD432
CD622
RS232
RS232 interface
X6
ENCODER
IN
Encoder cable interface
X7
CD432
CD622
R/S/T
Main power supply （ CD432 ： Single phase or 3-phase
AC220V，CD622：3-phase AC380V）
RB+/RB-
Braking resistor interface
DC+/DC-
DC bus power supply(Cannot use together with R/S/T)
