Kinco CD620 - Parameter List: Group F004 (to Set Motor Parameters)

42
d3.39
25080910
Position_Reach_Ti
me
Indicates the position reached time window
in the pulse mode
Unit: mS
10
0~32767
d3.40
2FF10108
Din_Position_Sele
ct_L
To select which parameter will be set.
0. Din_Pos0
1. Din_Pos1
2. Din_Pos2
3. Din_Pos3
4. Din_Pos4
5. Din_Pos5
6. Din_Pos6
7. Din_Pos7
0
N/A
d3.41
2FF10210
Din_Position_M
Refer to d3.42
0
-32767~
32767
d3.42
2FF10310
Din_Position_N
Din_Pos L(Pulse number) =
Din_Position_M *10000+ Din_Position_N
0
-32767~
32767
d3.43
20200F10
Din_Control_Word
Input “Enable” signal controls the control
word.
0
N/A
d3.44
20201810
Din_Speed4_RPM
Multi-speed control: 4 [rpm]
0
N/A
d3.45
20201910
Din_Speed5_RPM
Multi-speed control: 5 [rpm]
0
N/A
d3.46
20201A10
Din_Speed6_RPM
Multi-speed control: 6 [rpm]
0
N/A
d3.47
20201B10
Din_Speed7_RPM
Multi-speed control: 7 [rpm]
0
N/A
Parameter List: Group F004 (To Set Motor Parameters)
Numeric
display
Internal
Address
Variable Name
Meaning
d4.00
2FF00308
Store_Motor_Data
1: Stores the set motor parameters
d4.01
64100110
Motor_Num
Host computer (ASCII code) numerical display (hexadecimal)
“00”..... ..... ...303.0
Note: To change this parameter, you need to save it with the
address “d4.00”, and restart it later.
d4.02
64100208
Feedback_Type
Type of encoders
001.1: Differential ABZ and differential UVW signals
001.0: Differential ABZ and UVW signals of TTL
000.1: ABZ of TTL and differential UVW signals
000.0: ABZ of TTL and UVW signals of TTL
d4.03
64100508
Motor_Poles
Number of motor poles pairs
[2p]
d4.04
64100608
Commu_Mode
Searching excitation mode
d4.05
64100710
Commu_Curr
Searching excitation current
[dec]
d4.06
64100810
Commu_Delay
Delay in searching excitation
[mS]
d4.07
64100910
Motor_IIt_I
Indicates current settings on overheat protection of motors
