20
DIR+
Direction or negative
pulse interface (+)
DIR-
Direction or negative
pulse interface (-)
B
GNDA
Analog signal ground
AIN1
Analog signal input interface 1. Input impedance: 200 K
AIN2
Analog signal input interface 2. Input impedance: 200 K
GNDA
Analog signal ground
OUT1+
Digital output
interface 1+
Maximum output current: 100 mA
Withstanding voltage:24V
OUT1-
Digital output
interface 1-
OUT2+
Digital output
interface 2+
OUT2-
Digital output
interface 2-
OUT3
Digital output
interface 3
OUT4
Digital output
interface 4
24VO
Power input port of digital output signals 5
COMO
Common port of digital output signals
OUT5+
Digital output
interface 5+
Maximum output current: 800 mA
OUT5-
Digital output
interface 5-
X2
CD420
U/V/W/PE
Power cable interface of a motor
L/N
Main power interface (single-phase 220 VAC)
RB+/RB-
Braking resistor interface
CD430
CD620
U/V/W/PE
Power cable interface of a motor
X3
CD420
CD430
CD620
ENCODER OUT
Signal output interface of a motor encoder
RS232
RS232 interface that communicates with a host PC or
controller
X4
CD420
CD430
CD620
ENCODER IN
Encoder interface of a motor
X5
CD430
CD620
R/S/T
Main power interface (single-phase or three-phase AC 220V
for CD430 and three-phase AC 380 V for CD620)
RB+/RB-
Braking resistor interface
DC+/DC-
DC bus interface(Cannot use together with R/S/T)
-----
CD420
CD430
CD620
SHIELD
Fixed terminal for the shielded wires of motor cables
