Update multiple PV segment and preset
value:0=No. 1=Yes
SM141.5
SM151.5
SM161.5
SM171.5
Reset interrupt variable:0=Yes. 1=No.
SM141.6
SM151.6
SM161.6
SM171.6
Reserved
SM141.7
SM151.7
SM161.7
SM171.7
Reserved
HSC0
HSC1
HSC2
HSC2
Description
SMW142
SMW152
SMW162
SMW172
Starting value of preset value table（It is offset
corresponding to VB0),it must be odd value.
It needs to pay attention that not all the control bits of the control byte is suitable for all
operation mode. For example, “Counting direction” and “Write counting direction in HSC” can
be only used in mode 0,1and 2 (Single-phase up/down counter with internal direction
control),if the operation mode is with external direction control, then these two bits will be
ignored.
The control byte, current value and preset value are 0 by default after power on.
 Status Byte
In SM area, each high-speed counter has a status byte, which indicates the current status
of high speed counter.
HSC0
HSC1
HSC2
HSC3
Description
SM36.0
SM46.0
SM56.0
SM126.0
Reserved
SM36.1
SM46.1
SM56.1
SM126.1
Reserved
SM36.2
SM46.2
SM56.2
SM126.2
Reserved
SM36.3
SM46.3
SM56.3
SM126.3
Fault in multiple PV value
table:0=No,1=Yes
SM36.4
SM46.4
SM56.4
SM126.4
Reserved
SM36.5
SM46.5
SM56.5
SM126.5
Current counting direction:
0 = Down; 1= Up
SM36.6
SM46.6
SM56.6
SM126.6
Current value equal to preset value:
0 = No,1 = Yes
SM36.7
SM46.7
SM56.7
SM126.7
Current value greater than preset value:
0 = No,1 = Yes
HSC0
HSC1
HSC2
HSC3
Description
SMB140
SMB150
SMB160
SMB170
Current PV segment No.(Start from 0)
