Kinco MK043E-20DT - PLC Specification

Kinco-MK
User Manual
6
Printer port
USB
Software
DTools programming + EdgeAccess for remote services + Kinco
Miot for IoT function
1.4.2 PLC specification
Parameters
MK070E-33DT
MK070E-32DX
MK043E-20DT
Power supply
Rated voltage
DC24V
Voltage range
DC20.4V－28.8V
I/O communication
Digital IO
DI 16*DC24V，
DO 14*DC24V
DI 16*DC24V，
DO 4*DC24V+12*Relay
DI 9*DC24V，
DO 9*DC24V
Analog IO
2*A，1*AO.
(Supports voltage and
current type)
None
2*AI
(only support voltage
type)
Expansion
Up to 8 module;Support KS series expansion module
Programming port
USB2.0 Slave
Serial port
2*RS485, PORT1&PORT2, Baudrate up to 115.2kbps.
Port 1:Support programing, Modbus RTU master and slave,Free protocol
Port 2: Modbus RTU master and slave,Free protocol
High speed counter
4
Support single,double UP/DOWN,AB phase pulse input.
4 max 50KHz.
High speed output
4
Q0.0,Q0.1,Q0.4 max output 50 Khz（The load resistance must be less than
3KΩ at maximum frequency）
Q0.5 max output 10Khz.
