Kinco MK043E-20DT - Chapter 3 Software Introduction; 3.1 HMI Programming Guide

Kinco-MK
User Manual
19

AI/AO Specification
Parameter
AI
Rated Power supply
DC 24V，≥100mA
Signal
4-20mA、1-5V、0-20mA、0-10V
Resolution
12 bits
Accuracy
0.3% F.S.
Signal limitation
Current signal input could not over 24mA，
Voltage signal input Could not over12V
Speed（each channel）
15 times/sec
input resistance
Current mode：<=250Ω
Voltage mode：>4MΩ
AO
Rated Power supply
DC 24V ≥100mA
Signal
4-20mA、1-5V、0-20mA、0-10V
Resolution(including symbol bit)
12 bits
Accuracy
0.3% F.S.
Speed（each channel）
15 times /s
Output resistance
Current mode:Maximum 500Ω
Voltage mode :Minimum 10KΩ
Chapter 3 Software Introduction
3.1 HMI programming
HMI programming software: Kinco DTools. Download link for HMI software
http://en.kinco.cn
3.1.1 Create project
Process to create project based on Kinco DTools.
1, create project
Open Kinco DTools
1.1 create new project
（1） click menu【File】--【new】 to create project；
