King gates Book - 1 - PRODUCT DESCRIPTION; 1 A - WARNINGS; 1 B - AVAILABLE VERSION; CONTROL UNIT TECHNICAL DATA

1
4
2 3
B
A
S1
M4X50
S3
4,2X9,5
S2
6,3X50
C
D
E
F
I
L
N
M
O
H
P
G
Book 550
Book 550 Led
Book 1000 Led
550
550
1000
Star GD 20
Star GD 20 Led
Star GD 40 Led
Newton max Content of the package
See picture 1
See picture 1
See picture 1
Motor
24 Vdc
24 Vdc
24 Vdc
Control unit Radio Receiver
Led
Code
Encoder
AVAILABLE VERSION - MOTOREDUCTOR
Grb 3 - Glb 3
Grb 23
Grb 4
1 x 3 m
2 x 1,5 m
3 m + 1 m
3 m
3 m
4 m
2,45 m
2,45 m
3,45 m
Kind of slide
Kind of transmission
Belt
Slide lenght
Code
Door max height
AVAILABLE VERSION - RAILS
Content of the package
See pictures 2 and 3
See pictures 2 and 3
See pictures 2 and 3
CONTROL UNIT TECHNICAL DATA
Maximum torque
No load speed of the shaft
Nominal speed of the shaft
No load speed of the carriage
Nominal speed of the carriage
Maximum frequency working cycles
Control unit supply
Motor output
Motor power
Courtesy light
Flashing lamp output
Accessories output
Stop input
Antenna input
Radio receiver on board
Working temperature
Level of protection
Dimensions and weight
Max dimensions overhead door
9 Nm
50 Rpm
55 Rpm
13 cm/s
12 cm/s
70 cycles/day
230 ± 10% (50-60 Hz)
24 V
40 W
Light on board (24V,10W)
24V (max 15W)
24V (400 mA)
NC
52 ohm (RG58)
433.92 MHz (max 50 radiotransmitters)
da -20 a +55 °C
IP40
380x246x96 mm / 5 kg
8 mq
19 Nm
54 Rpm
42 Rpm
11 cm/s
9 cm/s
80 cycles/day
230 ± 10% (50-60 Hz)
24 V
80 W
A LED (24V)
24V (max 15W)
24V (400 mA)
NC
52 ohm (RG58)
433.92 MHz (max 50 radiotransmitters)
da -20 a +55 °C
IP40
380x246x96 mm / 5 kg
12 mq
Book 550 Book 1000 Led
1A - WARNINGS
1B - AVAILABLE VERSION
1 - PRODUCT DESCRIPTION
Before installing the product ascertain that safety conditions are observed according to the law, rules and regulation.
Use personal safety devices and locate warning signs on the motorized gate. Unfulfilment of the below listed direction will release
the Antoniolli Mario & C. sas, holder of the KING gates mark, from any responsibility for damage caused to people or things.
-Ascertain the integrity of the packing when opening it.
-In case of anomalies in the functioning, turn immediatly off the gear motor, disconnect electrical power and operate the gate
manually the problem has been found and salved.
-Do not modify the product in any part.
-Only authorized and qualified staff is alloned to disassemble the product.
-Prevent any part of the automation from being next to any source of heat or in contact with liquid substances.
-Use only adeguate power supply cables.
-To optimize the functioning of the automation, King gates accessories only.
-Disposal of waste material has to observe local regulations.
-Installing, testing and first functioning have to observe the laws in force.
