5.7#PAS#Level#Selection#
Short press the "UP" or “DOWN” button to switch the PAS level, the motor output power will be
changed accordingly by the PAS level of E-bike. The default range of PAS level is 0-5 levels. Level 1 is
the lowest output level, and the level 5 is the highest output power level of the motor.
PAS level indicator
5.8#Battery#Indicator#
The battery power status is displayed in the form of grid. The indicator is divided into five grids. When
the power is low, the color will turn red to remind the user to get the battery charged.
Battery indicator
5.10#Error#Code#
When the e-bike electronic control system fails, the display will automatically indicate the error code.
For the definition of detailed error codes, see appendix 1.
